How do I install Legitronic Labeling Software?Refer to: (PDF)Do I need a license to run Legitronic Labeling Software?Refer to: (PDF)What does a 'dongle not found' error in Legitronic 3.X mean?1. Check part number on the dongle:a) 41514 - Parallel Dongle Professional Versionb) 45243 - USB Dongle Professional Versionc) 45244 - Parallel Dongle Secure Series Versione) 45242 - USB Dongle Secure Series Version2. Check the Operating System on your PC. If it is Windows NT, or higher, a Sentinel Driver needs to be installed.

• R Download

Follow these steps for sentinel driver installation:a) If you have a USB dongle, unplug it from the port until this procedure is complete.b) In Windows select Start Programs Weber Marking Systems Legitronic Labeling Software For Windows Sentinel Installer or NT Sentinel Device Driver.c) Install the driver using default settings. Reboot the computer if prompted.How can I get a printer driver for Legitronic versions 3.X?The printer drivers are included on the Software Installation CD.How do I install a printer driver in Legitronic versions 3.X?Refer to: (pdf)Why does only part of my label print when using Legitronic 3.X?Refer to: (PDF)How do I change the printer darkness setting?1.

Open your label for design and select the 'File' menu and then select 'Printer Setup.' Select 'Send Darkness Command' if you want the label format to control this setting, and change the value under 'Setup Darkness.' Select 'Use Printer's Darkness Setting' if you would like the printer to control the darkness.How do I change the print speed?1. Open your label for design and select the 'File' menu and then select 'Printer Setup.' Select 'Send the Print Speed Command' if you want the label format to control this setting and change the value under 'Setup Speed.' Select 'Use the Printer's Speed Setting' if you would like the printer to control the print speed.The label constantly prints too high or too low on my media. How can I adjust this?1.

Open your label for design and select the 'File' menu and then select 'Printer Setup.' Select 'Send the Label Top Command' if you want the label format to control this setting and change the value under 'Setup Label Top.' Select 'Use Printer's Label Top Setting' if you would like the printer to control the Label Top.What does an ODBC error mean?There are various ODBC errors possible. The following items may help in troubleshooting ODBC errors.1. Setup ODBC connection;2. Check the Data Property of your fields on a label and make sure that they all reference the name from Step 1.3.

Never use a default name for the Data Source like: dBase Files, Excel Files, MS Access Database.4. Make sure that the Data Source Name is available for the user that is printing labels.5. If the database file was updated, make sure that none of the column headings or table names were changed. The label template won't recognize the new names.6. If the database table name or columns headings were changed in the database, the label format needs to be modified to reflect the new names.Refer to: (PDF)Also refer to: (PDF)What is ODBC?Short for Open DataBase Connectivity, a standard database access method developed by the SQL Access group in 1992. The goal of ODBC is to make it possible to access any data from any application, regardless of which database management system (DBMS) is handling the data. ODBC manages this by inserting a middle layer, called a database driver, between an application and the DBMS.

A detailed resource for entry-level engineering personnel in EW, military personnel with no radio or communications engineering background, technicians and software professionals, the work helps you understand the basic concepts required for modeling and simulation, as well as fidelity and other practical aspects of simulation design and application. Introduction to electronic warfare modeling and simulation ebook. Written by a well-known expert in the field with more than 24 years of experience, the book explores EW applications and techniques and the radio frequency spectrum, with primary emphasis on HF (high frequency) to microwave.

The purpose of this layer is to translate the application's data queries into commands that the DBMS understands. For this to work, both the application and the DBMS must be ODBC-compliant - that is, the application must be capable of issuing ODBC commands and the DBMS must be capable of responding to them. Since version 2.0, the standard supports SAG SQL.Source. What does a 'security module not found' error mean in Legi for Windows 2.X?A security module (also called a dongle) is a hardware license that is used with Legi for Windows. Legi for Windows version 2.X has a security module with PN: 38323. The printer cable does not need to be connected to the security module.

To troubleshoot 'security module not found' error, please follow these steps:1. Check the version of your PC Operating System. The security module is compatible only with Windows 3.1, Windows 95, and Windows 98.2. Plug the security module into the parallel port on your PC.3. If the same parallel connection is used for the printer, change the parallel port configuration in Windows to 'Printer Port' from the default 'EPC Printer Port.' How do I install a printer driver in Legi for Windows version 2.X?Legi for Windows version 2.X has its own drivers and does not use standard Windows drivers.

To install a driver, select 'Configuration' from the main Legi for Windows, then select 'Printers.' Select your printer from the printer list and click on 'Connect to Port.' Where can I get printer drivers for Legi for Windows version 2.X?In Legi for Windows versions 2.X, drivers are part of this 16-bit program. Please see How to install a printer driver in Legi for Windows version 2.X.X for more information.How do I change the printer darkness setting?1. Select 'Label Design' and open your label template.2.

Select the 'Settings' menu, then select 'Label' and 'Printers' options.3. Change the value of the darkness.4. Enter 999 for the darkness setting if you want to use the printer's darkness setting.How do I change the print speed?1. Select 'Label Design' and open your label template.2. Select the 'Settings' menu, then select 'Label' and 'Printers Options.' Change the value of the print speed.4.

R Download

Enter 999 for the print speed setting if you want to use the printer's speed setting.The label content prints too high or too low on my media. How can I adjust this?1. Select 'Label Design' and open your label template.2. Select the 'Settings' menu, then select 'Label' and 'Printers Options.' Change the value of Label Top Adjustment setting.4. Enter 999 for the Label Top Adjustment setting if you want to use the printer's Label Top setting.What does a 'null global memory block' error mean?This error may appear with any Legi for Windows 2.X versions. Follow these steps to correct this issue:1.

Select the 'Start' menu in Windows, and then select 'Search' or 'Find'. Search for the following files on the C: (Local Hard Disk) or any other driver that might contain Legitronic files:a) Paradox.lckb) Pdoxusrs.lckc) Pdoxusrs.netd).tmp2. Delete all files that were found in Step 1.3. Restart Legi for Windows version 2.X.What does an 'error opening language table' error mean?This error may appear with any Legi for Windows 2.X version. Follow these steps to correct this issue:1.

Select the 'Start' menu in Windows, and then select 'Search' or 'Find'. Search for the following files on the C: (Local Hard Disk) or any other driver that might contain Legitronic files:a) Paradox.lckb) Pdoxusrs.lckc) Pdoxusrs.netd).tmp2. Delete all files that were found in Step 1.3. Restart Legi for Windows version 2.X.What does an 'paradox' error mean?This error may appear with any Legi for Windows 2.X version. Follow these steps to correct this issue:1. Select the 'Start' menu in Windows, and then select 'Search' or 'Find'.

Search for the following files on the C: (Local Hard Disk) or any other driver that might contain Legitronic files:a) Paradox.lckb) Pdoxusrs.lckc) Pdoxusrs.netd).tmp2. Delete all files that were found in Step 1.3. Restart Legi for Windows version 2.X. What is a dongle?A dongle is one of the licensing methods that Legitronic uses. It is a hardware module that can be parallel or USB. During software installation, the 'Hardware Key Single User' option must be selected for the license type to use this type of licensing.Image examples: USB Dongle, Parallel DongleWhere does a dongle connect?If it is a parallel dongle, it will connect directly to your computer's parallel port and other parallel devices might be connected through it; for example, another printer.If it is a USB dongle, it will connect directly to any USB port on the PC.What does an 'Unable to Communicate with the printer' error mean?1. Check the communication settings used on the printer and the computer port; these have to match exactly.

The default serial communications settings on most printers is Baud rate (bits per second) 9600, Parity-None, Stop Bits 1, and Host Handshake (flow control) Xon/Xoff.2. In Windows Printers and Faxes area, check the 'Ports' tab under printer's properties and make sure 'Enable Bi-directional Support' is unchecked.3. For serial communications, make sure that a Weber printer cable is used.What does a 'Printer Offline' error mean?Go into the printer driver properties and open the 'Ports' tab. Uncheck the 'Enable Bi-directional Support' option, and reboot the computer.Can I use Legitronic Labeling Software with Windows Vista?Software version 3.6.2 will run on 32 bit versions of Windows Vista, Business and Ultimate, and 32 bit Vista will run on 64 bit machines.

At this time, only Zebra printer drivers for Vista are included in Legitronic 3.6.2.Early in 2010 we will be releasing Legitronic Labeling Software version 3.6.3 which will include 32 bit drivers for Sato printers. Note that LLS 3.6.3 will only run on the same 32 bit operating systems as listed above.Can I use Legitronic Labeling Software with Windows 7?Software version 3.6.6 up to current versions v3.7.x will run on Windows Professional 7, 8 and 10 (32 & 64 bit) Operating systems. The software also supplies printer drivers for Zebra, Sato and Datamax printers.The latest versions of Legitronic softwarte v3.7.3 and higher have 'signed drivers' and are the better version to run on the latest operating systems of Windows 8 & 10 that require 'signed drivers'. Otherwise if you are using a prior version of Legitronic software version 3.6.6 you need to disable the driver signature enforcement under your Windows operating system settings. How do I use Legitronic to Design and Print Labels?Using Legitronic to Design and Print Labels will show you all you want to know about designing and printing your labels. Additionally, the CD you received your Legitronic software on contains an unabridged User Guide.How do I set up a database connection using Legitronic version 3.0.X - 3.5.X?Refer to: (PDF)How can I use Tracking Serial Numbers with Legitronic 3.X?Refer to: (PDF)How do I make a UPC Shipping Container Symbol (ITF-14)?Refer to: (PDF)How do I set up an ODBC connection for an Excel Spreadsheet with using Legitronic v3.6.2 &/or Later?Refer to: (PDF)How do I install a USB printer driver for Legitronic versions 3.5.1 and higher?Refer to: (PDF).

If I decide to upgrade my version of Legitronic, will it still work with my Windows Operating System?There are three main software releases of Legitronic:1. Legitronic80 - This is an 8-bit labeling software that runs the MS DOS operating system.

It also may be installed and used on Windows 3.1, Windows 95 and Windows 98.2. Legitronic For Windows version 2.X - This is a 16-bit version of labeling software that may be used with Windows 3.1, Windows 95, and Windows 98 with a designated parallel port for the license key.3. Legitronic Labeling Software 3.X - This 32-bit version may be used on Windows 2000 Professional, Windows XP Professional, and 32 bit versions of Windows Vista, Business and Ultimate operating systems.Can I convert a Legitronic 2.2.0 label format to Legitronic version 3.X?It has been 10 years since the first 32 bit version of Legitronic was released. The last update to the 16 bit Legi for Windows 2.2.0 was Release 4, and was written to address Y2K issues. Hardware platforms, operating systems, and application software programs have changed many times in the decade between LegiWin 2 and the current version of Legitronic Labeling Software. As such, some of the technological chasms are too wide to cross.

That being the case, it is well worth weighing the effort spent trying to bring your old labels forward into a new version of software against that of simply creating new labels. Either way, you will spend considerable time and effort on the project and you will still have to learn to use the new software.Legi for Windows 2 Series labeling software came in several versions from 2.0 to 2.2. These are 16 bit applications developed for Windows for 3.11 to 9X. While the latest version, 2.2, can be migrated directly into Legitronic Labeling Software 3.6, the earlier versions cannot. And again, a 2.2 label may not function in 3.6.This is a lengthy, very detailed and highly technical process and it is entirely possible that the label format file will be corrupted during this process or that the file will simply fail to migrate into the new software. This process cannot be performed quickly, or 'walked through' over the phone.

You will have to touch each label several times in both the old and the new software. You will need to be fluent in using MS Windows XP Professional, including some of the more advanced features such as setting up ODBC driver links and OLE DB driver links. You will need to have access to a Windows XP Professional login account with administrative permissions over the system you will be working with.

You will also need to know how to work with MS Access or the database program you will be using.Additionally all versions of the Legi for Windows 2 Series software came with their own integrated Paradox database utility. The Paradox tables created with Legi for Windows 2.2 can be imported directly into MS Access 2003, while the Paradox tables created with Legi for Windows 2.1 and earlier cannot.

The 2.1 Paradox tables must be exported into and saved as a CSV file before they can be opened in MS Access 2003.Weber Packaging Solutions, Inc. Product Systems management reserves the right to determine whether or not a particular application is a good candidate for migration.Refer to: (PDF)Can I use my old Legitronic 2.X database with the current versions of Legitronic Labeling Software?No.

The older versions used a database management system that is not ODBC compliant. You must convert the database to one that is ODBC compliant.Refer to:How do I convert a Legitronic 2.2.0 database to a MS Access database to be used with Legitronic version 3.X?Refer to: (PDF)Can I update my old DOS Legitronic label formats to the current versions of Legitronic Labeling Software?No.

The older DOS versions ran in an 8 bit operating environment. The current version runs in a 32 bit operating environment. In the middle there were versions that ran in a 16 bit operating environment. This means that the as Operating Systems have changed in fundamental architecture three times, (soon four, with the release of Windows Vista) so has Legitronic Labeling Software. There is so much effort involved in trying to migrate from 8 bit to 16 bit to 32 bit versions of Legitronic, and so much functionality is lost that it requires less effort to start fresh.Refer to: (PDF).
